Mechanical Specifications
| Outer dimensions(L*W*H) | 2384*1303*35 mm |
| Cell Type | Ptype Mono-crystalline |
| No.of cells | 120(6*20) |
| Frame technology | Aluminum,silver anodized |
| Front glass thickness | 3.2 mm |
| Cable length(IEC/UL) | Portrait:300mm;Landscape:1400mm |
| Cable diameter(IEC/UL) | 4mm²/12AWG |
| Maximum mechanical test load | 5400Pa(front)/2400Pa(back) |
| Connector type(IEC/UL) | HCB40/MC4-EVO2(optional) |
| Module weight | 134.8 kg |
| Packing unit | 31 pcs/box(Subject to sales contract) |
| Weight of packing unit (for 40'HQ container) | 1125kg |
| Modules per 40'HQ container | 527 pcs |
